AutoCAD 2D Basics – Tutorial to draw a simple floor plan

0 Comments

This is a simple tutorial to draw a floor plan using Autocad. by Cad in Black (youtube)

In this Autocad video explains how to insert doors, window or other elements in a floor plan. Tips for saving time and drawing with precision.

CONTENTS: IV. Breaking walls – Insert lines (1:00) – cutting walls with TRIM (2:22) V. Doors – How to draw a door (3:23) – Convert to a BLOCK (5:42) – Change the door in different positions (6:20) – Place doors and windows (7:37) LIST OF COMMANDS USED (8:46)

Part 2, Autocad tutorial on floor plan
